画面太小、安装距离不够？换一颗镜头就能解决。SD10+ 适配 33 款松下机型，往下看清单。
佐西卡 SD10+ 投影机镜头
SD10+ 适用机型清单（共 33 款，附亮度/分辨率/变焦比）
以下为 SD10+ 已验证的适用机型（松下投影机），逐台附亮度、分辨率与变焦比：
| 投影机机型 | 亮度 | 分辨率 | 变焦比 |
|---|---|---|---|
| PT-FRZ68C/CL | 6800 流明 | WUXGA 1920×1200 | — |
| PT-FRZ98C/CL | — | WUXGA 1920×1200 | / |
| PT-FRW93C/CL | 9300 流明 | 1280×800 WXGA | / |
| PT-FRW73C/CL | 7300 流明 | 1280×800 WXGA | — |
| PT-FRZ78C/CL | 7800 流明 | WUXGA 1920×1200 | / |
| PT-FRZ88C/CL | 8800 流明 | WUXGA 1920×1200 | / |
| PT-FRZ120C | 12000 流明 | WUXGA 1920×1200 | / |
| PT-FRZ67C | 6700 流明 | WUXGA 1920×1200 | — |
| PT-FRQ080C | 8000 流明 | WQXGA 2715 x1697 | — |
| PT-FRX110C | 11000 流明 | WUXGA 1920×1200 | / |
| PT-FRZ99C | 10000 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRZ89C | 8800 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRZ79C | 7200 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRZ69C | 6200 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRQ100C | 10000 流明 | WQXGA 2715 x1697 | / |
| PT-RCQ10 | 10000 流明 | WQXGA 2715 x1697 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RCQ80 | 8000 流明 | WQXGA 2715 x1697 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RZ120 | 12000 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RZ990 | 9400 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RZ890 | 8500 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RZ790 | 7000 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RZ690 | 6000 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RQ7 | 7500 流明 | 4K (3840×2160) | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RQ6 | 6500 流明 | 4K (3840×2160) | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRQ65 | 6500 流明 | 4K (3840×2160) | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRQ75 | 7500 流明 | 4K (3840×2160) | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRZ75 | 7500 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RZ7 | 7500 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRZ65 | 6500 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-RZ6 | 6500 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRZ86 | 8600 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRQ86 | 8600 流明 | 4K （3840×2160） | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| PT-FRZ88 | 8600 流明 | WUXGA 1920×1200 | ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
说明：亮度、分辨率、变焦比取自佐西卡产品数据库（以机型铭牌/说明书为准）；镜头兼容性以机身接口和光学结构为准，清单外机型可联系佐西卡技术确认。
这颗镜头的规格
| 镜头型号 | SD10+ |
| 适配品牌 | 松下 |
| 适配机型亮度 | 6000–12000 流明 |
| 适配机型分辨率 | WUXGA 1920×1200、1280×800 WXGA、WQXGA 2715 x1697、4K (3840×2160)、4K （3840×2160） |
| 变焦比 | /、ET-DLE020(0.280–0.299) ET-DLE035(0.380) ET-DLE055(0.785) ET-DLE060(0.60–0.801) ET-DLE085(0.782–0.977) ET-DLE105(0.978–1.32) ET-DLE150(1.30–1.89) ET-DLE170 (1.71–2.41) ET-DLE250(2.27–3.62) ET-DLE350(3.58–5.45) ET-DLE450(5.36–8.58) |
| 投射比 | 0.72-1.15:1 |
| 适用机型数量 | 33 款 |
以上参数来自佐西卡产品数据库，如需完整技术规格书可联系销售索取。
你可能想问
问：镜头对不上画面大小怎么办？
答：先确认机型的镜头接口和光轴位置，再按实际安装距离选择对应投射比的镜头；拿不准就把安装距离和幕布尺寸发给佐西卡技术，我们帮你推荐。
问：我的机器不在上面 33 款清单里，能用 SD10+ 吗？
答：清单是已验证的机型，不代表全部。同品牌同代工程机常共用镜头接口，把机身铭牌和原镜头拍照发给佐西卡技术确认更稳妥。
问：镜头能替代原厂的吗？
答：镜头是投影光路的核心，直接决定清晰度和色彩。佐西卡镜头（型号见上文规格表）按原厂光学参数（焦距、投射比、镜片组）逐项对标，镜片镀膜工艺一致，成像锐利、边缘不发虚；普通替代镜头往往用普通玻璃镜片，镀膜层数不足，亮度损失和色偏一眼可见。工程和展览场景，建议优先佐西卡。
问：为什么选佐西卡而不是原厂？
答：佐西卡镜头按原厂光学图纸生产，镜片组、镀膜、投射比逐项对标，出厂前逐支做解像力测试。相比原厂，交期更短、综合更优；相比其他替代镜头，光学素质有数据保证。
问：镜头质保期多久？
答：佐西卡全系投影机镜头提供 12 个月保修；正常使用、非人为损坏（如磕碰、进水、私拆）可直接联系售后处理，质保期以出货单据日期为准。
同样规格，为什么推荐佐西卡
针对 SD10+ 这类工程镜头，佐西卡按原厂光学参数（焦距、投射比、镜片组）逐项对标，镜片镀膜工艺一致，成像锐利、边缘不发虚，装机即用。
佐西卡同规格替代型号，适用于松下 PT-FRZ68C/CL、PT-FRZ98C/CL、PT-FRW93C/CL、PT-FRW73C/CL、PT-FRZ78C/CL 等 33 款机型；在佐西卡官网查询系统输入 SD10+，即可查到完整适用机型清单。
- 光学对标：焦距、投射比、镜片组按原厂参数匹配
- 解像力测试：出厂前逐支测试，MTF 数据可查
- 镀膜工艺：镜片镀膜与原厂同级，减少光损
- 供货稳定：支持批量采购与项目供货
一句话总结：镜头是光学核心，别拿画面质量赌差价 —— 佐西卡投影机镜头按原厂图纸生产，综合更有优势。
说明：实际成像表现受机身状态和安装环境影响，批量采购前建议先取 1 支做实测。
换镜头时注意什么？
- 换镜头先断电：拆装镜头前务必关机并等散热风扇停转，避免带电操作损坏接口。
- 别碰镜片：手印和油污会直接影响画质，拿镜头抓镜筒不碰镜片；有灰尘用气吹轻吹，不要用布干擦。
- 对焦后再锁紧：安装到位后先对焦测试，再锁紧固定螺丝，避免长期使用松动导致画面漂移。
- 关注接口清洁：卡口和触点积灰会导致接触不良，换镜头时顺手清理更稳妥。
